Evidence for quasiperiodicity in orbital period modulation of WW Cygni


The Algol type binary system WW Cygni is known to display an intricate orbital period variability phenomenon which consists in the presence of an alternating component superposed on a secular trend.

The alternating component clearly deviates from a strictly periodic pattern. In the present paper we studied WW Cyg using a data set consisting of 309 times of primary minimum, free of outliers, covering a time base of 113.8 yr.

We investigated these timing data using periodicity detection methods relying on both amplitude spectrum and enhanced self-correlation (ESC) methods through Monte Carlo simulations.

The problem of estimation of the statistical significance in the ESC method was further developed. The multiperiodicity of the Oresiduals was investigated via iterative prewhitening using three types of models consisting of polynomial (P) + multiperiodic (MP) terms, P + light travel time effect (LTTE) terms, and P + MP terms + LTTE terms.

The interpretation of the results led us to the following two hypotheses: (i) a quasiperiodic modulation at a time scale of about 46 yr induced by the cyclic magnetic activity occurring in the cool secondary component of WW Cyg, or (ii) the coexistence of a periodic modulation with a period of 50.41 yr related to the presence of an unseen compact stellar object of at least 2.22 M⊙ in the system and a quasiperiodic modulation at a time scale of about 19.7 yr, caused by the mechanism (i).


A. Pop,

M. Crăciun,

G.R. Mocanu,

C. Vamoș


Binaries: eclipsing · Stars: individual: WW Cyg · Methods: data analysis, statistical

Cite this paper as:

A. Pop, M. Crăciun, G.R. Mocanu, C. Vamoș, Evidence for quasiperiodicity in orbital period modulation of WW Cygni, Astrophysics and Space Science 362: 76. (2017)



Applegate, J.H.: Astrophys. J. 385, 621 (1992)
ADS CrossRef Google Scholar




About this paper


Astrophysics and Space Science

Publisher Name


Print ISSN


Online ISSN






Google Scholar


[1] Applegate, J.H., A mechanism for orbital period modulation in close binaries, Astrophys. J. 385, 621 (1992)
CrossRef (DOI)

[2] Applegate, J.H., Shaham, J., Orbital period variability in the eclipsing pulsar binary PSR B1957+20: Evidence for a tidally powered star, Astrophys. J. 436, 312 (1994)
CrossRef (DOI)

[3] Balaji, B., Croll, B., Levine, A., Rappaport, S., Tracking the stellar longitudes of starspots in short-period Kepler binaries, Mon. Not. R. Astron. Soc. 448, 429 (2015)
CrossRef (DOI)

[4] Blažko, S., Über die Periode des Algolveränderlichen WW Cygni, Astron. Nachr. 220, 239 (1924)
CrossRef (DOI)

[5] Borkovits, T., Hegedüs, T., On the invisible components of some eclipsing binaries,
Astron. Astrophys. Suppl. Ser. 120, 63 (1996)
CrossRef (DOI)

[6] Borkovits, T., Hajdu, T., Sztakovics, J., Rappaport, S., Levine, A., Bíró, I.B., Klagyivik, P., A comprehensive study of theKeplertriples via eclipse timing, Mon. Not. R. Astron. Soc. 455, 4136 (2016)
CrossRef (DOI)

[7] Buchler, J.R., Kolláth, Z., Serre, T., Mattei, J., Nonlinear Analysis of the Light Curve of the Variable Star R Scuti,  Astrophys. J. 462, 489 (1996)
CrossRef (DOI)

[8] Ceraski, W., Une nouvelle variable 154. 1904 Cygni, Astron. Nachr. 166, 77 (1904)
CrossRef (DOI)

[9] Chamel, N., Haensel, P., Zdunik, J.L., Fantina, A.F., On the maximum of neutron stars, Int. J. Mod. Phys. E 22, 1330018 (2013)
CrossRef (DOI)

[10] Craciun, M., Vamos, C., Pop, A., Detection of low-lewel periodic signals through enhanced sefl-correlation method. The case of ER vulpeculae, Mon. Not. R. Astron. Soc. 448, 2066 (2015)
CrossRef (DOI)

[11] Deeming, T.J., Fourier analysis with unequally-spaced data, Astrophys. Space Sci. 36, 137 (1975)
CrossRef (DOI)

[12] Dugan, R.S., Wright, F.W.: CoPri 19, 36 (1939)

[13] Elias, N.M., Güdel, M., Radio observations of peculiar emission-line Algol binary stars, Astron. J. 106, 337 (1993)
CrossRef (DOI)

[14] Frescura, F.A.M., Engelbrecht, C.A., Frank, B.S., Significance of periodogram peaks and a pulsation mode analysis of the Beta Cephei star V403 Car,  Mon. Not. R. Astron. Soc. 388, 1693 (2008)
CrossRef (DOI)

[15] Graff, K., Elemente und photometrische Lichtkurve des Algolveränderlichen WW Cygni,  Astron. Nachr. 217, 349 (1922)
CrossRef (DOI)

[16] Güdel, M., Elias, N.M., Rôle des représentations des apprenants : expérimentation relative au climat motivationnel, in: ASP CS vol. 93, p. 312 (1996)
CrossRef (DOI)

[17] Hall, D.S., The relation between RS CVn and Algol, Space Sci. Rev. 50, 219 (1989)
CrossRef (DOI)

[18] Hall, D.S., In:Ibanoglu, C. (ed.) Active Close Binaries, p. 95. Kluwer Academic Publishers, Dordrecht (1990)
CrossRef (DOI)

[19] Hall, D.S., Wawrukiewicz, A.S., The eclipsing binary WW Cygni, an unlikely candidate for pre-main-sequence contraction, Publ. Astron. Soc. Pac. 84, 541 (1972)
CrossRef (DOI)

[20] Hartman, J.D., Bakos, G., Stanek, K.Z., Noyes, R.W, HATnetVariability Survey in the High Stellar Density “Kepler Field” with Millimagnitude Image Subtraction Photometry, Astron. J. 128, 1761 (2004)
CrossRef (DOI)

[21] Hinse, T.C., Horner, J., Wittenmyer, R.A., An orbital stability study of the proposed companios of SW Lyncis, J. Astron. Space Sci. 31, 187 (2014)
CrossRef (DOI)

[22] Hinse, T.C., Lee, C.W., Gozdziewski, K., Haghighipour, N., Lee, C.- U., Scullion, E.M., New light-travel time models and orbital stability study of the proposed planetary system HU Aquarii,  Mon. Not. R. Astron. Soc. 420, 3609 (2012)
CrossRef (DOI)

[23] Hoffman, D.I., Harrison, T.E., McNamara, B.J., Vestrand, W.T., Holtzman, J.A., Barker, T.: Astron. J. 132, 2260 (2006)

[24] Kalimeris, A., Rovithis-Livaniou, H., Rovithis, P., Starspots and photometric noise on observed minus calculated (O–C) diagrams, Astron. Astrophys. 387, 969 (2002)
CrossRef (DOI)

[25] Khaliullin, Kh.F., Khaliullina, A.I., δ Scuti light variations as a test for choosing the mechanism of cyclic orbital period changes in Algols, Mon. Not. R. Astron. Soc. 419, 3393 (2012)
CrossRef (DOI)

[26] Khaliullin, Kh.F., Khaliullina, A.I, Orbital-period variations in the eclipsing binary Y Cam,  Astron. Rep. 57, 517 (2013)
CrossRef (DOI)

[27] Kim, C.-H., Jeong, J.H., Demircan, O., Müyesseroglu, Z., Budding, E., The period canges of YY Eridani, Astron. J. 114, 2753 (1997)
CrossRef (DOI)

[28] Konacki, M., Maciejewski, A.J, A Method of Verification of the Existence of Planets around Pulsars, Icarus 122, 347 (1996)
CrossRef (DOI)

[29] Konacki, M., Maciejewski, A.J, Frequency Analysis of Reflex Velocities of Stars with Planets,  Astrophys. J. 518, 442 (1999a)
CrossRef (DOI)

[30] Konacki, M., Maciejewski, A.J, Methods of searching for planets around pulsars, Mon. Not. R. Astron. Soc. 308, 167 (1999b)
CrossRef (DOI)

[31] Kopal, Z.,  Dynamics of Close Binary Systems. Reidel, Dordrecht (1978)
CrossRef (DOI)

[32] Kuschnig, R., Weiss, W., Gruber, R., Bely, P.Y., Jenkner, H.: Astron. Astrophys. 238, 544 (1997)

[33] Lanza, A.F., Rodonò, M., Rosner, R., Orbital period modulation and magnetic cycles in close binaries,  Mon. Not. R. Astron. Soc. 296, 893 (1998)
CrossRef (DOI)

[34] Larsson, S., SiO maser emission and the intrinsic properties of Mira variables, Astron. Astrophys. 265, 133 (1992)
CrossRef (DOI)

[35] Lewin, W.H.G., van Paradijs, J., van der Klis, M., A review of quasi-periodic oscillations in low-mass X-ray binaries, Space Sci. Rev. 46, 273 (1988)
CrossRef (DOI)

[36] Lubow, S.H., Shu, F.H., Gas dynamics of semidetached binaries, Astrophys. J. 198, 383 (1975)
CrossRef (DOI)

[37] Mennickent, R.E., Otero, S., Kołaczowski, Z., Interacting binaries W Serpentids and double periodic variables,  Mon. Not. R. Astron. Soc. 455, 1728 (2016)
CrossRef (DOI)

[38] Mezzetti, M., Cester, B., Giuricin, G., Mardirossian, F., Revised photometric elements of eight SD-systems, Astron. Astrophys. Suppl. Ser. 39, 265 (1980)

[39] Middleditch, J, Two-second variability in AM Herculis binaries,  Astrophys. J. 257, L71 (1982)
CrossRef (DOI)

[40] Mikulášek, Z., Paunzen, E., Netopil, M., Zejda, M.: In: Balega, Yu. Yu., Romanyuk, I.I., Kudryavtsev, D.O. (eds.) Physics and Evolution of Magnetic and Related Stars. ASP CS, vol. 494, p. 230. Astronomical Society of Pacific, San Francisco (2015)

[41] Moss, D., Piskunov, N., Sokoloff, D., Nonaxisymmetric cool spot distributions and dynamo action in close binaries, Astron. Astrophys. 396, 885 (2002)
CrossRef (DOI)

[42] Murray, C.D., Dermott, S.F., Solar System Dynamics. Cambridge University Press, Cambridge, New York, Melbourne (1999)

[43] Nason, M.E., Moore, R.C., Observed minima of selected eclipsing variables. Astron. J. 56, 182 (1951)
CrossRef (DOI)

[44] Paparó, M., Szeidl, B., Mahdy, H.A., The high amplitude delta Scuti star SZ Lyncis revisited. Astrophys. Space Sci. 149, 73 (1988)
CrossRef (DOI)

[45] Patterson, J., Rapid oscillations in cataclysmic variables. VI – Periodicities in erupting dwarf novae. Astrophys. J. Suppl. Ser. 45, 517 (1981)
CrossRef (DOI)

[46] Patterson, J., Robinson, E.L., Nather, R.E., Rapid and ultrarapid oscillation in RU Peg. Astrophys. J. 214, 144 (1977)
CrossRef (DOI)

[47] Paunzen, E., Mikulášek, Z., Poleski, R., Krticka, J., Zejda, M., The (non-)variability of magnetic chemically peculiar candidates in the Large Magellanic Cloud, Astron. Astrophys. 556, A12 (2013), 9 p.
CrossRef (DOI)

[48] Percy, J.R., Mohamed, F.: J. Am. Assoc. Var. Star Obs. 32, 9 (2004)

[49] Percy, J.R., Palaniappan, R.: J. Am. Assoc. Var. Star Obs. 35, 290 (2006)

[50] Percy, J.R., Terziev, E.: J. Am. Assoc. Var. Star Obs. 39, 1 (2011) Percy, J.R., Hosick, J., Leigh, N.W.C.: Publ. Astron. Soc. Pac. 115, 59 (2003)

[51] Percy, J.R., Jakate, S.M., Matthews, J.M., Short-period light variations in Be stars.  Astron. J. 86, 53 (1981)
CrossRef (DOI)

[52] Percy, J.R., Ralli, J.A., Sen, L.V., Analysis of AAVSO visual observations of ten small-amplitude red variables. Publ. Astron. Soc. Pac. 105, 287 (1993)
CrossRef (DOI)

[53] Percy, J.R., Molak, A., Lund, H., Overbeek, D., Wehlau, A.F., Williams, P.F., V725 Sagittarii: From Population II Cepheid to Red Semiregular Variable. Publ. Astron. Soc. Pac. 118, 805 (2006a)
CrossRef (DOI)

[54] Percy, J.R., Gryc, W.K., Wong, J.C.-Y., Herbst, W., Self‐Correlation Analysis of the Photometric Variability of T Tauri Stars. Publ. Astron. Soc. Pac. 118, 1390 (2006b)
CrossRef (DOI)

[55] Percy, J.R., Harlow, C.D.W., Wu, A.P.S., Short‐Period Variable Be Stars Discovered or Confirmed through Self‐Correlation Analysis ofHipparcosEpoch Photometry.  Publ. Astron. Soc. Pac. 116, 178 (2004)
CrossRef (DOI)

[56] Percy, J.R., Hosik, J., Kincaide, H., Pang, C., Autocorrelation Analysis ofHipparcosPhotometry of Short‐Period Be Stars. Publ. Astron. Soc. Pac. 114, 551 (2002)
CrossRef (DOI)

[57] Percy, J.R., Esteves, S., Lin, A., Menezes, C., Wu, S.: J. Am. Assoc. Var. Star Obs. 37, 71 (2009)
[58] Peterson, W.M., Mutel, R.L., Güdel, M., Goss, W.M.: Nature 463, 207 (2010)

[59] Plavec, M.J.: Space Sci. Rev. 50, 95 (1989) Pop, A.: Rom. Astron. J. 6, 147 (1996)

[60] Pop, A.: PhD Thesis, Astronomical Institute of the Romanian Academy, Bucharest (1998)

[61] Pop, A.: Rom. Astron. J. 9, 141 (1999a)

[62] Pop, A.: Inf. Bull. Var. Stars, No. 4801 (1999b)

[63] Pop, A.: In: Sterken, C. (ed.) The Light-Time Effect in Astrophysics. Causes and Cures of the O−C Diagram. ASP CS, vol. 335, p. 263 (2005)

[64] Pop, A.: Rom. Astron. J. 17, 35 (2007)

[65] Pop, A., Vamos, C.: Rom. Astron. J. 17, 101 (2007)

[66] Pop, A., Vamos, C.: NewA 17, 667 (2012)

[67] Pop, A., Vamos, C.: NewA 23–24, 27 (2013)

[68] Pop, A., Liteanu, V., Moldovan, D.: Astrophys. Space Sci. 284, 1207 (2003)

[69] Pop, A., Turcu, V., Marcu, A.: Astrophys. Space Sci. 333, 17 (2011)

[70] Pop, A., Vamos, C., Turcu, V.: Astron. J. 139, 425 (2010)

[71] Prager, R.: Astron. Nachr. 249, 417 (1933) Rafert, J.B.: Publ. Astron. Soc. Pac. 94, 485 (1982)

[72] Retter, A., Richards, M.T., Wu, K.: Astrophys. J. 621, 417 (2005)

[73] Richards, M.T., Albright, G.E.: Astrophys. J. Suppl. Ser. 88, 199 (1993)

[74] Richards, M.T., Albright, G.E.: Astrophys. J. Suppl. Ser. 123, 537 (1999)

[75] Richards, M.T., Agafonov, M.I., Sharova, O.I.: Astrophys. J. 760, 8 (2012), 10 p.

[76] Richman, H.R., Applegate, J.H., Patterson, J.: Publ. Astron. Soc. Pac. 106, 1075 (1994)

[77] Robinson, E.L., Nather, R.E.: Astrophys. J. Suppl. Ser. 39, 461 (1979)

[78] Roy, A.E.: Orbital Motion, 4th edn. IOP Publishing, Bristol and Philadelphia (2005)

[79] Samolyk, G.: J. Am. Assoc. Var. Star Obs. 43, 77 (2015a)

[80] Samolyk, G.: J. Am. Assoc. Var. Star Obs. 43, 238 (2015b)

[81] Skillman, D.R., Patterson, J.: Astron. J. 96, 976 (1988)

[82] Sterken, C.: In: Sterken, C. (ed.) Interplay of Periodic, Cyclic and Stochastic Variability in Selected Areas of the H-R Diagram. ASP CS, vol. 292, p. 437 (2003)

[83] Struve, O.: Astrophys. J. 104, 253 (1946)

[84] Szebehely, V., Zare, K.: Astron. Astrophys. 58, 145 (1977)

[85] Terziev, E., Percy, J.R., Henden, A.A.: J. Am. Assoc. Var. Star Obs. 39, 162 (2011)

[86] Tran, K., Levine, A., Rappaport, S., Borkovits, T., Csizmadia, Sz., Kalomeni, B.: Astrophys. J. 774, 81 (2013), 14 p.

[87]  van der Klis, M.: Annu. Rev. Astron. Astrophys. 27, 517 (1989)

[88] Völschow, M., Schleicher, D.R.G., Perdelwitz, V., Banerjee, R.: Astron. Astrophys. 587, A34 (2016), 11 p.

[89] Warner, B.: Nature 336, 129 (1988)

[90] Watson, C.A., Dhillon, V.S.: Mon. Not. R. Astron. Soc. 351, 110 (2004)

[91] Watson, C.A., Marsh, T.R.: Mon. Not. R. Astron. Soc. 405, 2037 (2010)

[92] Whitney, B.S.: Astron. J. 62, 371 (1957)

[93] Wood, D.B., Forbes, J.E.: Astron. J. 68, 257 (1963)

[94] Yoon, T.S., Honeycutt, R.K., Kaitchuck, R.H., Schlegel, E.M.: Publ. Astron. Soc. Pac. 106, 239 (1994)

[95] Zavala, R.T.: In: Sterken, C. (ed.) The Light-Time Effect in Astrophysics. Causes and Cures of the O − C Diagram. ASP CS, vol. 335, p. 137 (2005) Z

[96] avala, R.T., McNamara, B.J., Harrison, T.E., Galvan, E., Galvan, J., Jarvis, T., Killgore, G., Mireles, O.R., Olivares, D., Rodriguez, B.A., Sanchez, M., Silva, A.L., Silva, A.L., Silva-Velarde, E.: Astron. J. 123, 450 (2002)

[97] Zavala, R.T., McNamara, B.J., Harrison, T.E., Bogue, H., Maness, H.L.: in: RevMexAA (Series Conferencias) vol. 20, p. 87 (2004)
